Name: Water Mains

Display Field: CarteID

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><P STYLE="font-size:16ptmargin:7 0 7 0;"><SPAN><SPAN>Waterlines including:</SPAN></SPAN></P><P STYLE="font-size:16ptmargin:7 0 7 20;"><SPAN><SPAN>TML - transmission lines: diameter&gt;= 14" </SPAN></SPAN></P><P STYLE="font-size:16ptmargin:7 0 7 20;"><SPAN><SPAN>ML - main lines </SPAN></SPAN></P><P STYLE="font-size:16ptmargin:7 0 7 20;"><SPAN><SPAN>FHL - fire hydrant leads</SPAN></SPAN></P><P STYLE="font-size:16ptmargin:7 0 7 0;"><SPAN><SPAN>Retired - waterlines that are abandoned or removed, but have maintenance history in the Cartegraph WO system.</SPAN></SPAN></P></DIV>

Service Item Id: b0fd0332a7f9494da99897e5f47da0a2

Copyright Text: Grapevine Public Works GIS

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.08122614741E7
YMin: 3879543.5908999965
XMax: -1.08058180027E7
YMax: 3884591.704999998
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 112, 255, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• CarteID ( type: esriFieldTypeString, alias: CarteID, length: 50 )
• ProjectNam ( type: esriFieldTypeString, alias: ProjectNam, length: 50 )
• ProjectID ( type: esriFieldTypeInteger, alias: ProjectID )
• Type ( type: esriFieldTypeInteger, alias: Type )
• MainTypeDe ( type: esriFieldTypeString, alias: MainTypeDe, length: 50 )
• Diameter ( type: esriFieldTypeInteger, alias: Diameter )
• MaterialTy ( type: esriFieldTypeString, alias: MaterialTy, length: 20 )
• WaterType ( type: esriFieldTypeString, alias: WaterType, length: 25 )
• DeadEnd ( type: esriFieldTypeString, alias: DeadEnd, length: 10 )
• Owner ( type: esriFieldTypeString, alias: Owner, length: 20 )
• InstallDat ( type: esriFieldTypeDate, alias: InstallDat, length: 8 )
• GISLength ( type: esriFieldTypeDouble, alias: GISLength )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
